ING Scientific Highlights
in 2000*

*Astronomical discoveries following from observations carried out with the ING telescopes. The report presented here is a preliminary version.

[ 1999 Scientific Highlights | 2001 Scientific Highlights

The following presents a selection of highlights, intended to be representative of the scientific quality and range of research being undertaken.




Nightly observations made since July 23 in different broadband filters with the Jacobus Kapteyn Telescope showed what appears to be the complete disruption of the nucleus of comet LINEAR, the brightest comet of the year.

The central condensation was highly condensed and showed the typical 'teardrop' form in the evening of July 23rd and July 24th, although its brightness decreased by a factor of about 3 between the two nights. In the evening of July 25th something very odd was happening to the comet: the central condensation was seen to be strongly elongated, with a very flat brightness distribution. The condensation's brightness faded further and its length increased on the following nights. On July 27 there was no evidence of any local brightness peaks that would indicate the presence of sub-nuclei.

In other words, it did not appear to have broken into individual fragments in the way that Comet Shoemaker-Levy 9 did in 1993. Instead, it had completely blown apart. The expansion velocity of the condensation was about 40 m/s, indicating that it was solid particles and not gas. The gas tail, which virtually had disappeared between July 23rd and 24th, had reformed as an extension of the major axis of the central condensation.

Figure 1. Comet LINEAR 23rd July. Figure 2. Contour levels on 23rd July.
JKT R-band image of Comet LINEAR on 23rd July. The central condensation showed the typical 'teardrop' form. [ JPEG | TIFF ] Contour levels of the comet's coma on 23rd July. [ JPEG | TIFF ]
Figure 3. Comet LINEAR on 26th July. Figure 4. Contour levels on 26th July.
Raw JKT R-band image of Comet LINEAR on  26th July. The central condensation was now strongly elongated, with a very flat brightness distribution. Coma's brightness had also faded and its length increased. [ JPEG | TIFF ] Contour levels of the comet's coma on 26th July. The unusual elongated shape was the first evidence of the comet's complete break-up. [ JPEG | TIFF ]

Further observations with the Isaac Newton Telescope confirmed the initial discovery and provided new insight into what the reason for the comet disruption could be: the evaporation of all the ice in the nucleus. Cometary nuclei are a mixture of solid lumps of material of various sizes, held together by a cement of ices. When comets pass close to the Sun during their journey across the solar system the icy elements (mainly water ice and carbon monoxide ice) sublime, leaving loose material behind that forms the dust tail of the comet, while the sublimed ice forms its gas tails. As a result of this process, or due to the strong gravitational pull from a planet such as Jupiter, or from the Sun, a comet nucleus may sometimes split into two or more fragments. What was seen in the case of Comet LINEAR, however, was different.

From analysis of the images astronomers concluded that this small comet probably ran out of ice altogether, leaving behind a loose conglomerate of particles that gradually dispersed into space. This model fitted the observations well, as measurements shown that the activity of the comet had been declining for several weeks as ice gradually sublimed away. During the comet's closest approach to the Sun, a burst of activity was recorded. Then, when all the ice was exhausted and nothing was holding together the solids, the nucleus began to fall apart.

The images taken with the Isaac Newton Telescope after break-up showed no sign of the comet's original nucleus, nor of any active sub-nuclei larger than a few metres across. Any large remnants of the nucleus that remained cannot be subliming significantly or they would have been detected in these images. Other comets are known to have disappeared, but Comet LINEAR is the first one to have been caught in the act.

Figure 5. Comet LINEAR on 1 August. Figure 6. Comet LINEAR on 1 August
This image, obtained on 1 August with the WFC on the INT, covers a field of view of 22 arcminutes and is processed to show the faint tail of the comet, which extends well beyond the edge of the field of view. [ JPEG | TIFF ] This another image, obtained on 1 August, is a 100-second exposure with the WFC on the INT. This section of the full image measures 4.5 arcminutes, equivalent to 110,000 km at the comet. This image is processed to show faint details in the coma of the comet. No features are seen in the image, which implied that no significant individual fragments more than a few metres across still emit gas. This demonstrates the catastrophic disruption of the nucleus. [ JPEG | TIFF ]

Some references:




Type Ia supernovae (SNe Ia) are one of the most important tools for observational cosmology because there appears to be a relatively small spread in their peak optical brightness and they can be seen out to cosmological distances so they can be used to measure cosmological parameters. However, the peak optical brightnesses of SNe Ia are not uniform; they are correlated with the shape of the light curve. Meaningful measurements of cosmological parameters require this variation to be calibrated. The corrections to peak brightnesses have to be empirical because it is still not yet clear what causes SNe Ia.

All the most likely models for progenitors of SNe Ia feature an accreting white dwarf which ignites carbon in its core either because it has reached the Chandrasekhar mass or because ignition of accumulated helium causes compression of the core and a so-called 'edge-lit detonation'. This explains the fast rise times for SNeIa, the lack of hydrogen and helium and the fairly uniform peak brightness. To initiate the explosion, the white dwarf must accrete material from a companion star. Two models for the companion star which have gained popularity in recent times are supersoft sources and double degenerates.

However, the possibility of a helium star companion to a white dwarf has not been widely considered as a source of SNe Ia. In particular, sub-dwarf B (sdB) star binaries might be good candidates. There are many white dwarfs which are known to begaining mass from a normal star, but these are made of hydrogen which causes a series of small explosions before the Chandresekhar limit is reached. This is what causes a nova explosion. To make a supernova, the white dwarf has to be supplied  with helium, which explodes less easily but releases much more energy.

KPD1930+2752 is a sdB star. It is about one fifth the size of the Sun and is about half as massive. Unlike normal stars, which are composed almost entirely of hydrogen, KPD1930+2752 is made of helium. It is not entirely clear how sdB stars are made, but recent work suggests they are the remains of stars like the Sun which lose half their mass just before they complete the end of the red giant phase of their evolution. Only some small fraction of stars evolve this way and this is thought to be related to the fact that most sdB stars are binary stars.

KPD1930+2752 was observed with the INT as part of a programme to study sdB stars to understand how they are formed. The Doppler shift shows that the star is orbiting an unseen companion every 137 minutes at a speed of 350 km/s. The unseen companion has almost the same mass as the Sun, but it is much smaller and fainter. The unseen companion star could be a neutron star or blackhole, but it is much more likely to be a white dwarf star.

When binary stars have orbital periods as short as two hours, they produce "gravitational waves" which drain energy from the orbit, so the stars gradually spiral in towards each other. KPD1930+2752 will merge within 200 million years. The white dwarf will then gain extra mass from the sdB star and will exceed the Chandresekhar critical mass. This is thought to lead to a Type Ia supernova explosion.

KPD1930+2752 is the first star to be discovered that is a good candidate for the progenitor of a Type Ia supernova of this type, which may explode on an astrophysically interesting time-scale.

Some references:



Most of the earlier images of Betelgeuse, made at wavelengths shorter than 800 nm, have exhibited a small number of bright regions. Astronomers have explained the bright regions as the tops of convection cells - bubbles of hot gas welling up from the interior of the star.

As we look at different wavelengths of light, we see to different depths in cool stars like Betelgeuse. The outer layers of the star are transparent to infrared light. Thus if we look in the infrared, we see a small, featureless star. The outer layers are not transparent to red light, because of absorption by titanium oxide molecules. However, if hot gas rising from below disturbs the outer layers, they become transparent to red as well as infrared light, and bright features are seen on the star, where hotter gas is visible through the "holes" in the outer layers.
The parametric images above were secured within a few days of each other in November 1997. The two images on the right were reconstructed using data from COAST, and the left-hand image is a result of an aperture-masking experiment performed in La Palma using the William Herschel Telescope. The resolution of all three images is similar (20-30 milliarcseconds), and each shows an area 0.1 arc-second across. Each image was taken through a different colour filter. From left to right, the images show how Betelgeuse appears in red (a wavelength of 700 nanometres), very near-infrared (905 nm), and near-infrared (1290 nm) light. To show this, we have coloured the images different shades of orange and red. The images are strikingly different from one other. Three bright features ("hotspots") are visible on the surface of the Betelgeuse at 700 nm, but only one feature is discernible at 905 nm, and at 1290 nm the star presents a featureless disk. The disk is also smaller at 1290 nm than at 905 nm, and its intensity falls off more sharply towards the edge.

Some references:



White dwarfs are the remnant cores of stars that initially had masses of less than 8 solar masses. They cool gradually over billion of years, and have been suggested to make up much of the 'dark matter' in the halo of the Milky Way. But extremely cool white dwarfs have proved difficult to detect, owing to both their faintness and their anticipated similarity in colour to other classes of dwarf stars.

A white dwarf star, named WD0346+246, was serendipitously discovered as a faint, very fast moving star on a sequence of photographic plates. The high apparent velocity is a characteristic of stars which are very old and are traveling on inclined elliptical orbits around the Galaxy. Astronomers secured parallax measurements on the Jacobus Kapteyn Telescope to determine the distance to WD0346+246 and confirm its low luminosity. They reported a distance of 28 parsecs. They also estimated a surface temperature of around 3,500 Kelvin degrees. Thus WD0346+246 has been shown to be one of the coolest and therefore oldest white dwarfs ever found, and has to be a member of a hitherto unobserved and possibly large population of faint stars in the Galactic halo.
WD 0346+246 spectrum
The spectrum of the halo white dwarf WD 0346+246 showing the dramatic effects of collision induced absorption by molecular hydrogen in the infrared. Thus the object appears red in the optical, but blue in the infrared. [ GIF | TIFF ]

This discovery has serious implications for our understanding of the Milky Way. The coolest white dwarfs provide a measurement of the age of the Galaxy. But they may also play a more important role. For the last thirty years, astronomers have found that most of our Galaxy seems to be invisible. In fact, as much as 90% of the mass in our Galaxy may be hidden in the form of 'dark matter'. Dark matter theories fall into two broad classes. The first suggests that the dark matter is not really dark - but is composed of many faint stars such as cool white dwarfs and brown dwarfs. The second class of dark matter candidates are various elementary particles, left over from the big bang. Indirect evidence for the dark matter being comprised of cool white dwarfs first came from the MACHO gravitational microlensing experiment. The MACHO project monitored some ten million stars in the Magellanic Clouds in the hope of detecting the occasional brightening caused by a dark halo object moving across our line of sight to one of the stars. The MACHO results suggest that these stars can be very numerous, and could contribute approximately 50% of the total mass of the Galaxy.

The discovery of one nearby, very old and cool white dwarf does not solve the dark matter problem. But it does lend weight to the MACHO scenario, and presents astronomers with an astonishing conclusion: the Galaxy may be full of extremely old white dwarf stars. The race is now on to count how many objects like WD0346+246 exist in the Galaxy and to measure how much they weigh in total.

Some references:

  • N. C. Hambly, S. J. Smartt, S. T. Hodgkin, R. F. Jameson, S. N. Kemp, W. R. J. Rolleston and I A Steele, 2000, "On the parallax of WD 0346+246: a halo white dwarf candidate", MNRAS, 309, L33.
  • S. T. Hodgkin, B. R. Oppenheimer, N. C. Hambly, R. F. Jameson, S. J. Smartt and I. A. Steele, 2000, "Infrared spectrum of an extremely cool white-dwarf star", Nature, 403 , 57.



Extragalactic planetary nebulae (PNe) are known in almost all galaxies of the Local Group. Most of them were discovered in the last decade by means of continuum-subtracted images in the bright nebular line of [O III]. M33, one of the two other large spiral galaxies of the Local Group besides the Milky Way, was the only major nearby galaxy which had not been searched for PNe yet. Astronomers aimed to fill up this gap taking advantage of new observational capabilities offered by the Wide Field Camera at the Isaac Newton Telescope. [O III], H-alpha and continuum images allowed astronomers to detect 134 candidate PNe in M33 and a large number of other emission line objects (mostly H II regions).

M33 galaxy.
This image is a composition of frames taken in three narrow bands: the green colour represents the galaxian emission in a filter centred on the [OIII] nebular line at 500.7nm, red is the H-alpha hydrogen emission at 656.3nm, while blue is mainly stellar light taken through a continuum filter centred at 555.0nm (Stromgren Y). In only one observing night, and with two positionings of the telescope, it was possible to cover the whole galaxy which has a size of approximately one degree in the sky. [ JPEG | TIFF ]

Some references:




Ultra-deep imaging observations using powerful, ground-based telescopes such as the William Herschel Telescope have the capacity to probe the evolutionary history of galaxies back to their formation epoch. At the faintest galaxy magnitudes, we are looking out not only in distance but back in time to when the Universe was only a few percent of its current age.

Over the past few years, astronomers have used the WHT to produce the deepest ground-based image of the sky which they have called the William Herschel Deep Field (WHDF). With exposures of ~30 hrs in U and B, the resulting images reach magnitudes which are comparable to the Hubble Deep Fields (U~27, B~28) but covering a five times bigger area of the sky than the two HDFs combined.

William Herschel Deep Field
A 'true' colour image of the William Herschel Deep Field, formed by mapping U, B and R exposures onto blue, green and red respectively. The image covers 7×7 arcminutes. [ JPEG | TIFF ]

For many aspects of the studies of high redshift galaxies, the bigger area of this Herschel Deep Field gives it a unique advantage over HST data. At intermediate redshifts (1<z<3) the larger numbers of galaxies means that they are more easily split into their various sub-populations by their colours. At high redshift, the big area means we have more chance of detecting candidates for galaxies in the redshift range 3<z<7 which are within the magnitude reach of multi-object spectrographs on 8–10m class telescopes for obtaining spectroscopic confirmation of their photometric redshift. The bigger area also has advantages for studies of high redshift galaxy clustering, aimed at understanding how structure forms in the early Universe.

In 1996, the ultraviolet and blue pictures in the WHDF revealed so many faint blue galaxies at a redshift of 2 that they already challenged the claims of the most popular cosmological theory, which suggested that galaxies formed around a redshift of 1, when the universe was half as a big as it is now. Since then, observations carried out at other telescopes have confirmed these results by finding many galaxies at redshifts of 3 and 4.  Now, applying similar techniques as before but to the new red and infra-red images from the WHT, astronomers find large numbers of galaxies at the even higher redshifts of 5 to 6, pushing the epoch of formation of giant galaxies back even earlier. There are as many galaxies at these redshifts as are found locally.

Differential galaxy number counts for the B-band.
This shows the B-band galaxy counts for the WHDF compared with other data, including the Hubble Deep fields. Also shown are the predictions for a universe in which galaxies do not evolve with time, and those for which galaxies follow simple stellar population synthesis tracks. Two geometries are considered, q0=0.05 (open) and q0=0.5 (flat). It is clear that non-evolving models underpredict the counts from quite bright magnitudes (B~22). Even an open evolving model struggles to keep up with the sheer numbers of galaxies seen, although there are probably enough uncertainties in this model to 'tweak' it higher at faint magnitudes. Those who favour a closed universe have to relax the constraint that galaxy numbers are conserved (e.g. merging) or at the very least invoke a population at high redshift which has disappeared from view by the present day (e.g. fading dwarfs). The model shown is a version of the latter. [ JPEG | TIFF ]

Some references:


There has been considerable progress in recent years in determining observational constraints on the cosmic history of star formation. Inevitably, most attention has focused on the contribution to the global history from the most distant sources, presumably seen at a time close to their formation. At more modest redshifts (z<1), it might be assumed that the cosmic star formation history is fairly well determined. However, the addition of further data to the low-redshift component of the cosmic star formation history has confused rather than clarified the situation. Using Autofib-2 on the William Herschel Telescope astronomers have conducted systematic spectroscopy of low-redshift 305 sources within two selected areas, updating the analysis of the ultraviolet luminosity function and star formation density presented in a previous work.

The luminosity function measures the number of galaxies of different brightness in the sky, and, from such measurements, the density of ultraviolet light can be measured. Ultraviolet light is generated by massive short-lived stars, and consequently traces the star-formation rate of the surveyed galaxies. By combining with measurements of another star-formation tracer, H-alpha emission lines, the two tracers of star-formation can be compared. This allows astronomers to place constraints on how the star-formation rate of the universe has evolved over time, or redshift.

One of the main conclusions of this survey is that the local volume-averaged star formation rate is higher than indicated  from earlier surveys. Moreover, internally within the sample, astronomers do not find a steep rise in the ultraviolet luminosity density with redshift over 0<z<0.4. These new data are more consistent with a modest evolutionary trend (M. Sullivan et al., 2000, "An ultraviolet-selected galaxy redshift survey - II. The physical nature of star formation in an enlarged sample", MNRAS, 312 , 442).
