| Item |
Contact |
Location |
Comments |
| Laser Stray Detector |
D.Cano |
GLAS cabinet, electronics spares box | We have a spare working PCB
and a spare box |
| IP66 female Connector |
D.Cano | GLAS cabinet, electronics spares box | RS: 261-6196, used in
the laser stray detectors |
| IP66 male Connector | D.Cano | GLAS cabinet, electronics spares box | RS: 261-5935, used in
the laser stray detectors |
| Laser Light Pulse
Detector |
D.Cano | GLAS cabinet, electronics spares box | Black box with transparent
window in the left side of the picture. Install pointing to the mirror M1 inside the laser enclosure |
| Laser Light Pulse
Detector receiver |
D.Cano | GLAS cabinet, electronics spares box | Install close to the
Stanford delay generator in GRACE. Note the unit on the right of the picture is intended only for spare and/or testing purposes, since it lacks the functionality to open/close the shutter in a continuous way. |
| Laser Light Pulse Detector receiver test cable | D.Cano | GLAS cabinet, electronics spares box | Used to test proper
trigger to the Stanford delay generator |
| Laser Head Box Temperature
Control Board |
D.Cano | GLAS cabinet, electronics spares box | Attention: care must
be taken to place the temperature sensors in their correct locations:
the laser box, the beam-dump (power meter) and the enclosure wall; two
more over-temperature sensors are located in the heater plates. See
documentation at:
http://redservices.ing.iac.es:8080/bscw/bscw.cgi/d98704/Temperature%20Control%20System%20Description%20and%20Calibration.pdf |
| GLAS Safety System LCD
Display |
CMP D.Cano |
PLC spares blue cabinet at
test focal station |
2 units. Do not take
out of the
anti-static protective bag, until is going to be used. Type
LCM-S04004DSF; Digikey: 67-1766-ND |
| Photodiode Irradiance
Meter |
D.Cano | GLAS cabinet, electronics spares box | Only to be used by
trained people. It is designed to measure the actual laser power output
at the BLT, to check the actual beam intensity profile. |
| GLAS Safety System LCD Message Controller | CMP D.Cano |
PLC spares blue cabinet at test focal station | Includes special spare cable
for the connection controller <--> LCD. See the picture. RS:
294-8847 |
| Laser Stabilization Mirror
Signal Conditioner |
D.Cano |
GLAS cabinet, electronics on top of spares box | Calibrated by RMR and DCano
5-V-09 (Note: Board functionality check OK, but connections not previously tested on the system) |
| Laser Stray Light Simulator |
D.Cano |
OPS head drawer |
Used for testing the laser
stray light detectors properly triggering of the GLAS safety system |
| RS232 Cable for Newport
Optical Power Meter |
D.Cano |
GLAS cabinet, electronics spares box | Has a special
micro-connector required by Newport 841-PE optical power meter located
in the laser enclosure |
Last updated by Diego Cano Infantes
May-2009
