INT Telescope Control System Release Notes for Version I19 TCS-INTREL-19 Issue: 1.3 2004-06-22 Authors: M P Fisher, R Rutherford tcsman@ing.iac.es

1. Summary

This document summarises the changes made to I18-0-1, the latest version in the I18 release tree of the INT Telescope Control System, to produce the release tree I19.

2. Release History

3. Hardware and Firmware Modifications

None

4. Deliverables and Installation

• The CMS classes necessary to build TCS versions in the I19 release tree are defined in Section 8, they are also defined in the version files in [INT_LOGIN.VERSION].
• CMS libraries containing the source code for the TCS, the PLOT and CAMTEST utilities, and the build procedures are held on LPAS3; the root directory for the CMS libraries is defined by the logical name SOURCE_DIR.
• The release notes document for the I19 release tree (this document) is stored in ~docs/tcs/intrel/tcs-intrel-19/tcs-intrel-19.html
• The Latex source for the INT User Manual is stored in ~mpf/docs/tcs/int_manual/. Note that this file needs updating. The Postscript version is in www.ing.iac.es/Astronomy/observing/manuals/ps/tcs/int.ps

5. Reasons for release

I19-0-0

New features

• The LOG command has changed fundamentally. The optional parameter period has been replaced by the parameter duration and the encoders are now logged every TCS cycle (currently 20Hz). The duration parameter is required for all types of log (encoder, autoguider or TV), if it is omitted the user is prompted and offered a default time of 15 minutes; the permitted range of duration is 1 - 120 minutes. The log will be closed after the specified time has elapsed; the logging time can be increased by re-issuing the LOG command with a longer duration. The log can be stopped early by the command LOG log-type OFF
• The dome position and position error are recorded in the encoder log.

Defects fixed

• FR 12787 : Longitude is written with the correct (negative) sign in the FITS headers
• FR 14637, 15135 : TELD crashed due to memory leak
• FR 15127 : default focus for WFC changed to 43.95

I19-2-0

New features

• Implements a fast pull-in of the guide star after every AUTO ON or AUTO RESUME command

Defects fixed

• None

I19-4-0

New features

• Kick actions no longer stop the telescope

Defects fixed

• None


6. Known problems and restrictions

Defect reports outstanding

• FR 10093 : Request to allow rotator movement from handset
• FR 11292 : Catalogue handling problem
• FR 12766 : Blind offset did not return to target
• FR 13213 : PF rotator s/w limit problem
• FR 13562 : Documentation needed on pointing tests
• FR 13712 : Improve CALIBRATE ANALYSE ZERO messages
• FR 13840 : TELD crashes when ICS sends command OFFSET ARC -0
• FR 14723 : TCS FITS header item EQUINOX is not FITS compliant
• FR 14811 : Request to allow Tabs in TCS catalogues
• FR 15201 : Request for shutter vignetting warning

Other problems

7. Compatibility

• Compatible with TPOINT v4.4-4.

8. Software changes

I19-0-0

I19-0-0 comprises the following subsystem versions; any changes made to a subsystem since I18-0-1 are listed.

BUILD v0-6

• Unchanged

CAMACDB v0-1

• Unchanged

DISPLAY v2-00

• Unchanged

EQUATLIB v1-0

• Unchanged

GSEXAM v0-1

• Unchanged

INCLIB v4-01

• LOG command parameter period changed to duration.

INT v5-02

• LOG command parameter period changed to duration.

INTINIT v3-05

• LOG command parameter period changed to duration.
• WFC default focus changed to 43.95
• IERS parameters updated.

MONITOR v0-3

• Unchanged

MSG v0-7

• Unchanged

NETSERVER v0-3

• This subsystem is not used by the INT TCS.

POINT v0-5

• Unchanged

RUN v1-03

• Unchanged

SHARE v0-3

• Unchanged

SYNC v3-04

• LOG command parameter period changed to duration.
• Encoder log includes dome position and position error.

SYSCOMP v1-00

• Unchanged

TCSLIB v1-02

• Unchanged

TELD v5-03

• Longitude is negative in FITS headers.
• CEFS are initialised before TELD is started.
• Memory leak (SDS id) fixed.

TV v1-01

• LOG command parameter period changed to duration.

USER v4-05

• LOG command parameter period changed to duration.

I19-2-0

I19-2-0 is the same as I19-0-0 apart from changes to the following subsystems.

SYNC v3-05

• Implemented fast pull-in after every AUTO ON or AUTO RESUME command

TV v1-02

• Set flags to implement fast pull-in after every AUTO ON or AUTO RESUME command

I19-4-0

I19-4-0 is the same as I19-2-0 apart from the changes to the following subsystem.

TELD v5-03A

• kick actions no longer stop the telescope
