JKT Telescope Control System
Release Notes for Version J11
TCS-JKTREL-11
Issue: 1.2 2002-11-05
Author: M P Fisher
|
1. Summary
This document summarises the changes made to the latest version in the
J10 release tree of the JKT Telescope Control System, J10-0-1, to produce
the release tree J11.
2. Release History
Version
|
Date
|
Description
|
Author(s)
|
J9-0-0
|
2-Oct-1999
|
TCS brought up-to-date, IERS parameters updated
|
MPF
|
J9-2-0
|
4-Apr-2001
|
Version for UltraDAS, uses DRAMA v1.3
|
MPF
|
J10-0-0
|
2-Jun-2001
|
New commands CLONE, GOMOON & SLOWOFF, IERS parameters updated,
includes latest fixes, uses Hytec driver v2-1
|
MPF
|
J10-0-1
|
13-Dec-2001
|
Update focus-temperature relationship
|
MPF
|
J11-0-0
|
19-Apr-2002
|
Log TELD messages, log focus encoder, negative longitude for
headers, updated IERS parameters
|
MPF/RR
|
J11-1-0
|
25-Oct-2002
|
New pointing model, fix memory leak in TELD, updated IERS
parameters
|
MPF
|
3. Hardware and Firmware Modifications
None
4. Deliverables and Installation
-
The CMS classes necessary to build TCS versions in the J11 release tree
are defined in Section 8, they are also defined in the version files in
[JKT_LOGIN.VERSION].
-
CMS libraries containing the source code for the TCS, the PLOT and
CAMTEST utilities, and the build procedures are held on LPAS3; the root
directory for the CMS libraries is defined by the logical name
SOURCE_DIR.
-
The release notes document for the J11 release tree (this document) is
stored in ~docs/tcs/jktrel/tcs-jktrel-11/tcs-jktrel-11.html
-
The Latex source for the JKT User Manual is stored in
~mpf/docs/tcs/jkt_manual/. Note that this file needs updating. The
Postscript version is in
www.ing.iac.es/Astronomy/observing/manuals/ps/tcs/jkt.ps
5. Reasons for release
J11-0-0
New features
-
The login window disappears once the TCS has been started.
-
TELD is started from a detached process.
-
TELD messages are logged to a file.
-
More robust method of reading the autoguider packets from CAMAC.
-
Encoder logs include the focus encoder.
-
Longitude is now correctly negative in the FITS headers.
Defects fixed
J11-1-0
New features
The new pointing model provides much improved pointing and tracking.
Defects fixed
-
FR 14848 : TELD crashed due to a memory leak
6. Known problems and restrictions
Defect reports outstanding
-
FR 10851 : CALIBRATE star S19+07 is a visual binary
-
FR 14423 : JAG filter status incorrect, because USER window was
on hold screen
Other problems
7. Compatibility
-
Compatible with TPOINT v4.4-4.
8. Software changes
J11-0-0
J11-0-0 comprises the following subsystem versions; any changes made to a
subsystem since J10-0-1 are listed.
BUILD v0-6
CAMACDB v0-1
DISPLAY v2-00
EQUATLIB v1-0
GSEXAM v0-1
INCLIB v4-00
-
Changes to support WHT and INT, they are not relevant to the JKT.
JKT v1-03
-
Improved method of reading the autoguider 3340 CAMAC module.
JKTINIT v1-5
-
IERS parameters updated.
-
Use correct encoder index for focus and dome mechanisms in
MEC_AL_ENCLIST.
MONITOR v0-3
MSG v0-7
NETSERVER v0-3
-
This subsystem is not used by the JKT TCS.
POINT v0-5
RUN v1-03
-
TELD is started as a detached process.
-
TELD CEFs are initialised before TELD is started.
SHARE v0-3
SYNC v3-01
-
Focus encoders are included in encoder logs.
-
New improved code to read 3340 CAMAC modules.
SYSCOMP v1-01
-
Ensure the COMMON block used for TCS-TELD communication is empty before
use.
-
CONFIG block is always sent to TELD on startup.
TCSLIB v1-02
-
New routine used by 3340 CAMAC code.
TELD v5-02
-
Log messages to a file.
-
TELESCOPE symbol is obtained from logical name set in the version file.
-
The correct telescope name is written in the startup message.
-
Initialise CEFs before starting TELD.
-
Get latitude and longitude from CONFIG block, where longitude is
negative, and not from sla_OBS which returns a west longitude as
positive.
TV v1-00
-
Support new autoguiding algorithm (not currently used at JKT).
USER v4-03
-
Improved communication with TELD.
J11-1-0
J11-1-0 is the same as j11-0-0 apart from changes to the following
subsystems.
OWNINIT v1-6
-
New pointing model, upated IERS parameters.
TELD v5-03
